Solar Ready Hot Water Cylinders: Building Consent Explained (NZ)

, , , ,

Adding solar hot water — or making a cylinder “solar ready” — usually involves roof work, plumbing, and sometimes electrical changes, so building consent is often required. The rules here are the existing Building Code requirements, not a new mandate. This guide sets out when consent is needed, which standards apply, and where a like-for-like replacement may be exempt.

Building Consent Requirements

In general, you need building consent for a solar ready hot water cylinder installation that involves structural modifications, roof penetrations, or plumbing and electrical work beyond a simple like-for-like swap. A council (building consent authority) has a statutory 20 working days to process a complete application.

Consent — the essentials

20 days
Statutory processing (working days)
G12 + E2
Key Building Code clauses
Schedule 1
Where a like-for-like swap may be exempt

Which Systems Require Consent

Installations involving new cylinder mounting, roof penetrations, or electrical upgrades generally require consent. A straightforward cylinder replacement using existing connections may be exempt under Schedule 1 of the Building Act — but adding solar collectors or new roof penetrations usually takes the job outside that exemption.

Compliance Standards

Solar water heating installations are covered by the plumbing and drainage standard AS/NZS 3500.4 (heated water services), alongside the manufacturer’s installation instructions and the Building Code. Copies of the standards can be purchased from Standards New Zealand.

solar ready hot water New Zealand

Building Code Requirements

Installations must meet Building Code clause G12 (Water Supplies) and, for any roof penetrations, clause E2 (External Moisture). The system also needs adequate pressure and temperature relief provisions in line with G12.

Pre-installation Documentation

A consent application typically includes the manufacturer’s specifications, structural details for the roof mounting, and the relevant plumbing and electrical documentation. Remember the council has up to 20 working days to process a complete application.

Exemption Categories

Limited exemptions apply to:

  • Like-for-like replacement using existing mounting points and connections
  • Minor work that does not involve structural changes or new roof penetrations
  • Work covered by an existing consent, or specific Schedule 1 exemptions

Council Inspection Requirements

Where consent is required, the council will usually inspect at rough-in (plumbing and electrical) and again at final, before issuing the code compliance certificate (CCC). Some councils accept remote or photo inspections for straightforward work.

Retrofit Considerations

On an existing home, the roof may need a structural check to confirm it can carry the collector and cylinder loads. Mains-pressure cylinders also need proper seismic restraint under the Building Code — this applies to cylinders generally, not just larger ones.

Wetback Hot Water Systems: NZ Wood Burner Integration Guide

, , , ,

A wetback hot water system heats your water off a wood burner or solid fuel heater. Because you can’t simply switch off the heat source, these systems carry strict, long-standing safety requirements — proper temperature and pressure relief, and correct expansion control. This guide explains how they work and what a safe, compliant install involves.

Understanding Wetback System Requirements

A wetback hot water system uses a heat exchanger inside your wood burner or solid fuel heater to heat water for household use. The water circulates between the heat exchanger and your hot water cylinder through thermosiphon action — hot water rises while cooler water sinks, creating natural circulation without pumps.

Wetback System Key Figures

60-80°C
Water temperature range
180-300L
Typical cylinder size
No pump
Natural thermosiphon circulation
20-25 years
System lifespan

A wetback needs the right safety fittings for what is an uncontrolled heat source: temperature and pressure relief, plus proper expansion provision. Many wetbacks are run as open-vented (low-pressure) systems for exactly this reason, though closed mains-pressure setups are possible with the correct controls. Installing or altering one generally requires building consent, given the solid-fuel heater and plumbing work involved.

Choosing Between Open and Closed Systems

Open vented systems use a header tank in your roof space to maintain constant water pressure and provide expansion space. The system vents excess pressure through an overflow pipe, making it inherently safer but requiring more complex plumbing and roof access for maintenance.

Closed mains pressure systems connect directly to your water supply and use pressure relief valves for safety. These systems provide better water pressure throughout your house but require more sophisticated safety controls. Your installer must size the expansion vessel correctly to handle thermal expansion when the wood burner operates at high output.

The choice depends on your existing plumbing configuration and whether you prioritise water pressure or system simplicity. Open systems suit older homes with existing header tanks, while closed systems work better in modern houses with mains pressure plumbing.

Integration with Modern Wood Burners

Contemporary wood burners often include wetback-ready designs with built-in heat exchanger mounting points. Your installer can retrofit wetback coils into some existing burners, but this requires careful assessment of the firebox size and heat output capacity.

wetback hot water systems New Zealand

The heat exchanger must handle your burner’s maximum output without overheating. Oversized wetback systems can cause the wood burner to run too hot, while undersized systems won’t provide adequate hot water. Professional sizing calculations consider your household’s hot water demand, burner output, and cylinder capacity.

Wetback setups are usually kept simple and robust. Some installs add a temperature gauge or a basic controller so you can keep an eye on the cylinder, but a wetback hot water system relies on natural circulation rather than electronics.

Safety and Backup Systems

Your wetback system needs backup heating for summer months when you don’t operate the wood burner regularly. Electric boost elements or separate gas systems ensure consistent hot water year-round. The backup system must integrate with the wetback controls to prevent conflicts between heat sources.

Tempering (thermostatic mixing) valves blend the stored hot water with cold before it reaches the taps, preventing scalding. They are especially important on wetbacks because solid-fuel heating can push stored water well above normal cylinder temperatures — and G12 already requires hot water to be delivered to taps at a safe temperature.

Pressure relief systems protect against thermal expansion and potential pressure buildup. Your system requires both temperature and pressure relief valves, positioned correctly and connected to appropriate drainage systems.

Questions to Ask Your Installer

Confirm whether your existing wood burner can accommodate a wetback heat exchanger without compromising its efficiency or safety certifications. Ask about the sizing calculations for your household’s hot water demand and whether the proposed cylinder capacity matches your usage patterns.

Understand the backup heating options and how they integrate with the wetback system. Request details about the safety systems including valve specifications and maintenance requirements. Clarify whether the installation requires building consent and what documentation you’ll receive for compliance records.

Ask about ongoing maintenance schedules for the heat exchanger, circulation system, and safety valves. Understand the warranty coverage for both the wetback components and integration work.

Why This Matters

Properly installed wetback systems provide cost-effective hot water heating using renewable wood fuel, reducing your electricity bills significantly during winter months. However, incorrect installation can create serious safety risks including scalding, pressure vessel failure, or carbon monoxide exposure if the wood burner installation is compromised.

A well-designed and properly installed wetback meets New Zealand’s safety standards while delivering the efficiency that makes these systems attractive for rural and eco-conscious households. Professional installation protects your investment and keeps it running reliably for decades.
